SH500 Calorific power meter
Adoption standard
GB/T213-2008 "coal calorific determination method", GB/T483-2007 "coal analysis test method general provisions", JC/T1005-2006 "cement black raw material calorific determination method", GB/T384 "petroleum products calorific value determination method".
Scope of application
Calorimeter is mainly used to determine the calorific index of coal, coke, gangue and other solid combustible materials, in order to measure the quality of the measured material.Widely used in power, coal, metallurgy, petrochemical, quality inspection, environmental protection and other industries.It is the main instrument in coal quality laboratory.
Performance characteristics
Main technical indicators
| Model | SH500 Calorific power meter |
| Power supply | AC (220V±10%), 50 Hz |
| Work rate | < 300W |
| Heat capacity | about 10500J/K |
| Resolution | 0.001 ℃ |
| Test time | about 15min |
| Temperature range | 5℃-40℃ |
| Temperature measurement range | 0℃-65℃ |
| Quantitative error | ≤±1g |
| Calorific measurement accuracy | better than 0.2% (benzoic acid) |
| Measurement error | better than national standard |
| outer water pipe capacity | 30L |
| Inner water drum capacity | 2.3L |
| Ignition voltage | 24V |
| gnition time | 6 minutes ignition |
| Measuring accuracy | GB/T213-2003 |
| Overall dimension (mm): 460 *440* 580 Host weight: about 30 kg | |
| Package size: 720 *580* 610 mm Package weight: 43 kg | |
Packing list
| S/N | Name | Unit | Quantity | Remarks |
|---|---|---|---|---|
| 1 | Calorimeter host | set | 1 | |
| 2 | Oxygen bomb | piece | 1 | |
| 3 | Oxygenator | piece | 1 | |
| 4 | Oxygen bomb rack | piece | 1 | |
| 5 | Crucible | piece | 2 | Vulnerable spare parts |
| 6 | 10mL syringe | piece | 1 | |
|
7 |
Rubber sealing ring |
set |
2 |
One set of oxygen filling instrument and one set of oxygen bomb Vulnerable spare parts |
| 8 | Ignition wire | piece | 1 | 0.18mm Ni-Cr wire, consumables |
| 9 | Cotton thread | piece | 1 | consumables |
| 10 | Benzoic acid | piece | 10 | consumables |
| 11 | Printing paper | piece | 2 | consumables |
| 12 | power cord | piece | 1 | 250V 6A |
| 13 | Instructions | copy | 1 | |
| 14 | Certificate warranty card | copy | 1 |
