ASTMD1665 IP212 GB/T266 Standard Engler Viscosimeter for Oil Product Analysis
SD266B petroleum products engler viscometer is according to the standard of the People's Republic of China GB/T 266 "engler viscosity measurement of oil products design and manufacturing requirements, applicable to the determination of liquid under the condition of a certain temperature, volume, flowed from engler viscometer time (in seconds) and distilled water in 20 ℃ when the ratio of the flow of time (in seconds), is the engler viscosity of liquid, the unit for his degree, but also suitable for the determination of emulsified asphalt and the coal tar to his viscosity, expressed in his degree (EV).
Standard:ASTMD1665 IP212 GB/T266
Engler Viscosimeter
Engler Viscometer,Petroleum Products Determination of Engler viscosity
Engler Viscometer of Petroleum Products
Washing oil Engler viscometer
Petroleum Products Engler Viscometer with Digital Display
Engler viscometer for petroleum product testing
I. Main technical features
1. The instrument is a table top, and its smoothness meets the requirements of the test.
2, outflow time digital display, can carry out parallel test of two samples at the same time, easy to use, high efficiency.
3, The temperature controller adopts digital temperature controller with P, I and D bit adjustment function, convenient parameter setting and high temperature control precision.
II. Main technical parameters and indicators
| 1 | Model No | SD266B |
| 2 | Product Name | Ensler viscometer for petroleum products (all-in-one) |
| 3 | Standard water value | (51±1)s |
| 4 | Temperature range | (room temp~100)ºC |
| 5 | Temperature control accuracy | ±0.1ºC |
| 6 | Engler viscosity thermometer | in line with the GB514 standard |
| 7 | Bottle size | (200±0.2)ml |
| 8 | Inner crucible | stainless steel material |
| 9 | Power of electric heater | 550W(AC220V, 50Hz) |
| 10 | Time measurement | maximum 999.9 seconds |
|
Size:320*260*430mm Weight:12kg
|
||
Packing list
| S/N | Name | Unit | Quantity | Remarks |
| 1 | Tester (host) | set | 1 | |
| 2 | Engler thermometer | piece | 1 | Mercury thermometers may not be transportable |
| 3 | Thermometer clamp | set | 1 | |
| 4 | Wooden stopper | piece | 1 | |
| 5 | PT100 sensor | piece | 1 | |
| 6 | Receiving bottle | piece | 1 | |
| 7 | Instructions | copy | 1 | |
| 8 | Certificate | copy | 1 |
