SD-6536C Manual Petroleum Distillation Analyser ASTM D86 Compressor Refrigeration

SD-6536C Manual Petroleum Product Distillation And Boiling Range Analyzer ASTM D 86 Compressor Refrigeration

The SD‑6536C Petroleum Products Distillation & Boiling Range Tester is developed and manufactured complying with Chinese standards GB/T 6536 Petroleum Products — Determination of Distillation Characteristics and GB/T 7534‑2004 Industrial Volatile Organic Liquids — Determination of Boiling Range.
The distillation range denotes the temperature interval between the initial boiling point and final boiling point. It reflects the evaporative properties of petroleum products when distilled under specified test conditions.
Definitions of boiling‑range terms: The initial distillation temperature is the temperature at which the first drop of condensate drips from the condenser tube during distillation. The final distillation temperature refers to the temperature measured near the end‑point of distillation. The temperature span between these two values constitutes the boiling range.
This instrument is applicable for distillation testing of gasoline, aviation gasoline, jet fuel, special‑boiling‑point solvents, naphtha, diesel fuel, distillate fuels and other similar petroleum products. It can also measure the boiling range of chemical substances including methanol.

Main technical parameters and characteristics

● The constant temperature bath is composed of a digital temperature controller, stainless steel heater, new refrigeration compressor, and electric stirrer, and the temperature inside the bath is uniform, fully meeting the requirements of the test.

● Adopting a special heating furnace form to ensure the safety of the test; The heating power is continuously adjustable to meet the requirements of the experiment.

● This instrument is fully equipped and easy to use. Purchasing the instrument allows for low-temperature distillation testing of petroleum products.

● The condensate tank is made of stainless steel and can be heated and cooled

● Refrigeration internal circulation, no need for cooling water external circulation

● Working power supply: AC 220V ± 10% 50Hz

● Rated power: approximately 2000W

● Heating power of electric furnace: 1000W

● Heating electric furnace: high-quality nickel cadmium alloy heating wire

● Heating electric furnace power ranging from 0 to 1000W, continuously adjustable

● Measuring cylinder volume: 100ml, division 1ml

● Distillation flask: 125mL, in accordance with the requirements of GB/T 6536

● Distillation pressure regulating furnace power: 0-1KW

● Condenser tube size: Φ 14 × 560 mm

● Material of condenser tube: seamless brass tube

● Condensation bath volume: 5.5L, actual liquid added 4.5L

● Heating method for condensation bath: electric heating rod heating

● Temperature control method for condensation bath: digital thermostat for temperature control

● Refrigeration system: new type of refrigeration compressor

● Temperature range of condensation bath: 0-400 ℃

● Maximum power of the whole machine: 1.45 KW

● Experiment quantity: single hole

● Instrument size: 420 × 520 × 500mm (L ×W × H)

● Instrument weight: 25kg

Note: The appearance pictures, dimensions, volume, and weight of the instrument are for reference only. If there are any updates to the instrument, there may be slight changes without prior notice.

Shandong Shengtai Instrument Co., Ltd. provides the following quality assurance for the instruments sold to you:

----The provided instrument materials are brand new, meet national quality standards, and have a manufacturer's certificate of conformity;

----The materials and main components provided meet the technical requirements specified in the technical documentation;

----The overall quality assurance period of the equipment is one year (excluding normal wear and tear of vulnerable parts).

----We are responsible for free maintenance of any instrument quality issues that occur during the warranty period. Due to equipment malfunction caused by the user's responsibility, we are responsible for repairing and charging reasonable fees.

----Lifetime discounted supply of parts for equipment, and lifetime maintenance and repair of the entire machine.

----After the expiration of the warranty period, if the user needs maintenance and technical services, we will only charge a cost fee.
