| Brand Name: | Shengtai Instrument |
| Model Number: | ST123 |
| MOQ: | 1 carton |
| Payment Terms: | T/T |
| Supply Ability: | 10 cartons per week |
ST123 Vegetable Oil Smoke Point Tester
LCD display screen; operating ambient temperature: -10 ℃ ~ 40 ℃; power supply: 220 V, 50 Hz
The ST123 Vegetable Oil Smoke Point Tester is professional equipment designed to test the smoke point of vegetable oils. It complies with Item 5 "Second Method – Visual Determination Method" specified in GB/T 20795-2006 Determination of Smoke Point of Vegetable Oils and AOCS Cc 9a-48.
It is widely applied in quality supervision, import & export inspection, oil production, oil storage and transportation, food manufacturing, scientific research, agricultural cultivation, universities and other institutions requiring smoke point testing for vegetable oils and fats.
Once continuous faint blue smoke (generated by thermal decomposition of grease) is observed, record the temperature reading and press the heat/lock button. The value displayed on the upper screen will be the smoke point. Featuring a simple and intuitive structure, this tester comes with an economical price.
Product parameters
| Double test error | ≤2°C |
| Result output mode | visual thermometer and digital display |
| Temperature measurement range | room temperature -300 °C, |
| Working environment |
temperature (-10~40) °C, relative humidity≤ 95%RH |
| Result display mode | visual temperature and digital temperature lock |
| Power supply | 220V, 50Hz |
| Weight | 10 kg, |
Packing list
| S/N | Name | Quantity | Unit | Remarks |
| 1 | HOST | 1 | set | |
| Oil cup | 2 | pieces | ||
| 2 | Power cord | 1 | article | |
| 3 | Fuse tube | 1 | pieces | Inside the sea t10A |
| 4 | Instruction manual certificate | 1 | copy | |
| 5 | Warranty card | 1 | copy |
