| Brand Name: | Shengtai Instrument |
| Model Number: | SH102A |
| MOQ: | 1 |
| Payment Terms: | T/T |
| Supply Ability: | 5000 sets / year |
SH102A Semi-Automatic Petroleum Density Meter Touch Screen & Precise Pt100 Temp Control Dual Holes ASTM D1298
PRODUCT DESCRIPTION
SH102A Semi-Automatic Petroleum Density Meter
Applicable Standards: GB/T 1884, ASTM D1298, GB/T 2281, GB 36170, GB/T 4472
Our SH102A density tester is built following GB/T 1884, the national standard for testing petroleum and liquid petroleum product density via hydrometer. Newly rolled out by our factory, this unit works great for density testing of crude oil and all liquid petroleum derivatives.
It fully meets test criteria from multiple authoritative standards: GB/T 1884 hydrometer test method for crude oil and liquid petroleum, ASTM D1298, GB/T 2281-2008 for coking oil density testing, GB 36170-2018 crude oil specifications, SH 0068 covering engine coolant density tests, plus GB/T 4472 for density and relative density measurement of chemical goods.
Core Advantages
- Easy temperature adjustment through a touchscreen panel.
- Fitted with a hard glass bath tank and electric stirrer, allowing clear sample viewing while keeping temperature evenly spread across the bath.
Technical Specifications
| Number of measurement holes | 2 holes |
| Bathtub capacity | Ф250 * 300mm |
| Test tube capacity | 500ml |
| Heating power | 700W |
| Temp control range | RT ～80℃ or 5℃ ～ 80℃(optional cooling) |
| Temp control accuracy | ±0.1℃ |
| Temp sensor | PT100 industrial platinum resistor |
| 10 sets of density tubes | Specifications: 600 ～ 1010 kg/m³ |
| Graduation value: 0.5 | |
| Total length: 300 mm | |
| Power supply | AC220V±10% 50Hz |
| Dimensions | 320*380*530mm |
| Weight | 12kg |
Note: The appearance images, dimensions, volume, and weight of the instrument are for reference only. Minor changes may occur if the instrument is updated, and no further notice will be provided.
Shandong Shengtai Instrument Co., Ltd. provides the following quality assurance for the instruments sold to your company:
The provided instruments and materials are new, comply with national quality standards, and come with manufacturer certificates of conformity;
The provided materials and main components comply with the technical requirements specified in the technical documentation;
The warranty period for the entire equipment is one year (excluding normal wear and tear of consumable parts).
For instrument quality issues arising within the warranty period, we will provide free repairs. For equipment failures caused by the user's responsibility, we will handle the repairs with reasonable charges.
Lifelong discounted supply of spare parts and comprehensive maintenance services for the entire machine.
After the warranty period expires, our company will only charge for the cost of repairs and technical services when the user requests them
Unlike most domestic manufacturers that only adhere to domestic standards, Shengtai Instruments optimizes its product design and supporting services for the global market:
Comprehensive coverage of multiple standards: The core products simultaneously meet the standards of various countries such as China's GB and the United States' ASTM, and the test results are recognized in the global oil trade scenarios.
